Description
Fixed transmitter, 626-668 MHz
-
Wireless (infrared) transmitter and receiver frequency synchronization system
-
“Easy setup” function for automatic search for free frequencies
-
42MHz bandwidth with 1680 selectable frequencies
-
Maximum RF transmitter output power 50mW
-
Transmitter with OLED display, ability to display the user’s name and indications of selected frequency, selected bank and channel number, AF signal level, transmission status, lock, input sensitivity, mute activation.
-
Compatible with previous generations of Evolution Wireless systems EW-G1, EW-G2, EW-G3
Main technical characteristics:
-
Modulation: Wideband FM stereo (MPX pilot tone)
-
Frequency range: Range B 626-668MHz
-
Receiving Frequencies: Up to 1680 frequencies in 25KHz steps
-
20 frequency banks, up to 16 channels factory set per bank
-
6 frequency banks, with 16 user-programmable channels per bank
-
Switching Bandwidth: 42MHz
-
S/N ratio: ?90 dBA
-
THD: ?0.9%
-
Headphone output: ?” (6.3 mm) stereo jack socket, balanced
-
Dimensions: 202 x 212 x 43 mm
-
Weight: 980 g
