Description
FEATURES
- Goof proof operation to smooth uneven levels, add sustain to guitars, fatten drums or tighten up mixes
- New gate timing algorithms ensure the smoothest release characteristics
- Program-adaptive expander/gates
- Great sounding dynamics control for any type of program material
- Separate precision LED displays for gain reduction, compression threshold and gate threshold allow quick, accurate setup
- Stereo or dual-mode operation
- Balanced inputs and outputs on 1/4″ TRS and XLR
- Side Chain insert
- Classic dbx® “Auto” mode
SPECIFICATIONS
| INPUT | |
| Connector: |
1/4″ TRS and XLR, Floating Balanced; XLR: Pin 2 hot Phone: Tip Hot HI |
| Impedance: | >50kΩ balanced, >25kΩ unbalanced |
| Maximum Level: | +24dBu, Balanced or Unbalanced |
| CMRR: | >40dB at 1kHz, typically >55dB |
| SIDECHAIN INSERT | |
| Connector: | 1/4″ TRS Phone, Normalled: Ring = Output (send); tip = Input (return) |
| Impedance: | Tip = >10kΩ (Input), Ring = 2kΩ (Output) |
| Maximum Level: | +24dBu |
| OUTPUT | |
| Connector: | 1/4″ TRS phone and XLR floating balanced, XLR: Pin 2 and Tip Hi |
| Impedance: | 120Ω balanced, 60Ω unbalanced |
| Maximum Level: | +21dBu,>+20 dBm into 600Ω, balanced or unbalanced |
| Frequency Response: |
20Hz – 20kHz; +0, -0.5dB, Typical 3dB points are 0.35Hz and 110kHz, unity gain |
|
Noise: |
<-90dBu, 22Hz to 22kHz, no weighting, unity gain |
| THD + N: | Typically <0.04%; Any Amount of Compression Up to 40dB@1kHz |
| SMPTE IMD | Typically <0.08% @ +10dBu (15dB Gain reduction) |
| COMPRESSION | |
| Threshold Range: | -40dBu to +20dBu |
| Threshold Characteristic: | Selectable OverEasy® or hard knee |
| Compression Ratio: | Variable; 1:1 to Infinity:1; 60dB Maximum Compression |
| Attack Time: | Variable program-dependent; 3ms to 340ms for 15dB gain reduction |
| Release Time: | Variable program-dependent; 200dB/Sec to 3dB/Sec |
| EXPANDER/GATE | |
| Threshold Range: | OFF to +15dBu |
| Expansion Ratio: | 10:1 |
| Maximum Depth: | >60dB |
| Attack Time: | <500µs (from Maximum Depth) |
| Release Time: | Adjustable, 30ms to 3sec (to 30dB attenuation) |
| SYSTEM | |
| PeakStop™ Limiter Threshold Range: | 0dBu to +20dBu |
| Gain Adjustment Range: | Variable; -20dB to +20dB |
| Interchannel Crosstalk | <-80dB, 20Hz to 20kHz |
| Dynamic Range: | >115 dB |
| Stereo Coupling: | True RMS Power Summing™ |
| POWER | |
| Power Consumption: | 15 Watts Maximum |
| Operating Temperature: | 0¾C to 45¾C (32¾F to 113¾F) |
| PHYSICAL | |
| Dimensions: | 1.75″ x 19″ x 6.75″ (4.45 cm x 48.2 cm x 17.15 cm) |
| Weight: |
Net weight: 5.05 lb (2.29kg) Shipping weight: 7.20 lb (3.27 kg) |
